Carbon Steels:
A105,A266 C11 to C14, SA765 Gr.2
A372 Gr.A/Gr.B
A350 LF2 C11 to C13 for low temperature service
A516 Gr.60 and Gr.70
S45C
A738C/S355J2/1.0577

Low Alloy Steels
Ferritic alloy steel forgings for high-pressure and high-temperature parts, such as boilers and pressure vessels.
A182/A336 F1, F5 F9,F11, F22, F91,F92

Austenitic stainless steels
A182 F304 /304L (UNS S30403), F310 (UNS S31000)
A182 F316/316L(UNS S31603), F316Ti, F317/317L (UNS S31703)
A18 F321 (UNS S32100), F347 (UNS S34700)
A182 F44 (254SMO), 904 L (UNS NO8904)
17-4 PH, 15-5 PH (SUS 630)

Alloy Steels (for machine building)
42CrMo4 (Q+T)/AISI 4140 /DIN EN 1.7225
25CrMo4 /AISI 4130 / DIN EN 1.7213
34CrNiMo6/AISI 4340 /DIN EN 1.6582
AISI 8660 Tripel Alloy Steel

High Strength / high yield carbon steels
A694 F42, F45, F52, F55, F60, F66, F70

Ferritic Stainless steels
A182 F429, F430, F440A

Martensitic Stainless steels
A182 F6a, A182 F6NM

WEIGHT OF STAINLESS STEEL PIPES & TUBES
[O.D.(mm)-W.T.(mm)xW.T.(mm)x0.02466=Kg.per meter

WEIGHT OF STAINLESS STEEL SHEETS
Length(Mtr.)xWidth (Mtr.)xThk(mm)x8=Kg. per Sheet

WEIGHT OF STAINLESS STEEL CIRCLE & BLANKS
O.D.(mm)xDia.(mm)xthk(mm)/260/1000=kg.per Pcs.

WEIGHT OF STAINLESS STEEL ROUND
Dia.(mm)xDia.(mm)x0.00623=Kg.per Meter

WEIGHT OF STAINLESS STEEL HEXAGONAL RODS
Dia.(mm)xDia.(mm)x0.00679=Kg.per Meter

WEIGHT OF STAINLESS STEEL SQUARE BARS
Dia.(mm)xDia.(mm)x0.00787=Kg. per Meter

WEIGHT OF CARBON STEEL PIPES & TUBES
[O.D.(mm)-W.T.(mm)]xW.T.(mm)x0.02466=Kg. per Sheet

WEIGHT OF CARBON STEEL SHEETS-PLATES
Length (Mtr.)xWidth (Mtr.)xThk(mm)x7.85=Kg.per Sheet

WEIGHT OF COPPER PIPES
[O.D.(mm)-W.T.(mm)]xW.T.(mm)x0.0256=Kg.per Meter

WEIGHT OF LEAD PIPES(APPROX)
[O.D.(mm)-W.T.(mm)xW.T.(mm)x0.0345=Kg.per Meter

WEIGHT OF LEAD SHEET (APPROX)
Length(Mtr.)xWidth(Mtr.)xThk(,mm)x11.2=Kg.per Meter

WEIGHT OF ALUMINIUM PIPES(APPROX)
[O.D.(mm)-W.T(mm)xW.T.(mm)x0.0082=Kg.per Meter

WEIGHT OF ALUMINIUM SHEETS(APPROX)
[O.D.(mm)-W.T.(mm)xW.T.(mm)x2.66=Kg. per Meter

SHEET WIDTH REQUIRED FOR ROLLED AND WELDED PIPES
[O.D.(mm)-Thk.(mm)]x3.14=Shet Width

Tensile Strength Conversion Table

1. Kg/mm2x9.81=N/mm2=Mpa
2.PSix0.0007=Kg/mm2
3.KSix1000=PSi
4.Kg/mm2x1.422=KSi
